Electric Stacker CDDK/CTDK series

Quick Contact

11300

There was a problem validating the form please check!
The connection to the server timed out!
Successfully sent!!

The CDDK/CTDK series electric stacker is designed for general warehouse use, capable of short-to-medium travel distances. The foldable stand-on platform gives operator more flexibility.

Features

  • Available with capacities from 1,200 to 1,500 kg
  • Multiple lift heights available – 3,000 / 3,300 / 4,500 / 5,000mm
  • Compatible with single-face, open face pallets only (CDDK series)
  • Adjustable legs to accommodate varying pallet widths or closed face pallets (CTDK series)
  • DC Brushless Traction Motor (for CDDK/CTDK12 only)
  • High-performance AC Traction Motor (CDDK/CTDK15 only)
  • German FREI Tiller Head
  • European Steel Mast
  • Side Battery Extraction
  • Emergency reversing switch and creep speed button for additional safety in tight spaces.
  • Automatic Speed Reduction on Cornering
  • Foldable Stand-on Platform and Guard, enabling either pedestrian or stand-on operation.
  • Electric Power Steering for additional operator comfort (CDDK/CTDK15 only)
  • Hall-effect control system, reducing wear and tear on components.
  • Equipped with Deep Cycle Battery (CDDK/CTDK12, CDDK/CTDK15-III)
  • Equipped with Traction Battery (CDDK/CTDK15-II)
Model Load Capacity Lifting Height Distance between Fork-Arms Battery Type Motor Type
CDDK12III-Li 1200 kg 3000 / 3300 mm 570 / 695 mm Lithium DC Brushless
CDDK15III-Li 1500 kg 3000 / 3300 mm 570 / 695 mm Lithium AC + EPS
CDDK15II-Li 1500 kg 4500 / 5000 mm 570 / 695 mm Lithium AC + EPS
CTDK12III-Li 1200 kg 3000 / 3300 mm 200 - 800 mm (Adjustable fork) Lithium DC Brushless
CTDK15III-Li 1500 kg 3000 / 3300 mm 200 - 800 mm (Adjustable fork) Lithium AC + EPS
CTDK15II-Li 1500 kg 4500 / 5000 mm 200 - 800 mm (Adjustable fork) Lithium AC + EPS
