Electric Reach Truck CQD20-D Series

Electric Reach Truck – Model CQD20-D

Powerful. Safe. Easy to Operate. Equipped with Smart Technology for Warehouse Operations.

The CQD20-D electric reach truck is designed to meet the demands of modern warehouse logistics, manufacturing, and distribution centers that require precision, agility, and safety. It features a high-performance AC motor, a maximum travel speed of 11 km/h, and a load capacity of up to 2,000 kg. The integrated Electric Power Steering (EPS) and dual-mode steering (180° / 360°) enable smooth maneuvering even in narrow aisles.

Key Features

• Smart start system with password access for enhanced safety at every start
• Large color display showing real-time status, wheel angle, speed, battery level, and alerts
• Fork-mounted camera improves visibility and precision when stacking goods at high levels
• Auto speed control adjusts according to steering angle and direction for safe operation
• Advanced braking system with dual-service brakes (Hydraulic + Regenerative) and automatic electromagnetic brake when parking
• In-seat Operator Presence System disables truck operation when the driver leaves the seat.
• Wide View Mast and redesigned overhead guard offer improved visibility
• Height positioning system with wire encoder for precise lifting from zero level

• Active Stabilization Control offers improved precise load handling and safety.

Ergonomic & Operator-Friendly Design

• Adjustable steering wheel (tilt and reach) for optimal control and comfort
• Adjustable cushion seat designed for long shifts with excellent back support
• Easy battery replacement via side-way battery removal system – no tools required

Battery & Structure Options

• Compatible with either Lead-acid Batteries or Lithium Batteries.
• Modular structure with one-piece top cover - allows quick and easy maintenance access

Lifting Performance

The CQD20-D series supports a wide range of lifting heights, from 5,000 mm to 14,000 mm, making it ideal for high bay warehouses and multi-tier racking systems.

Note: Free Lift is the maximum lift height the forks can reach without raising the mast - ideal for low-clearance areas like containers or low racking systems.


Load Capacity by Lift Height and Load Center
The load capacity of the CQD20-D varies based on the lift height and the load center (LC).

Notes:

• LC (Load Center) = distance from the load’s center of gravity to the heel of the fork. A higher LC reduces lifting capacity.
• The higher the lift height and the further the load extends, the lower the safe lifting capacity.

Example:

• Lifting at 6,000 mm with LC = 600 mm ➝ Max load: 2,000 kg
• Lifting at 14,000 mm with LC = 1000 mm ➝ Max load: 500 kg

Certified European Safety Standards (CE Certified)
Tested and compliant with global safety regulations:

• EN ISO 3691-1 - Safety of Industrial Trucks
• EN 1175 / EN 12100-1 - Electrical Systems and General Machinery Safety
• IP69 + 10G Shock Resistance - Specifically for fork-mounted camera

Option: Access Control (PIN Code Keypad)

The access control system with a PIN code keypad allows only authorized users to operate the equipment. It enhances safety, prevents incorrect or unauthorized use, and supports multiple user PIN codes to meet the organization’s specific requirements.

Choose the CQD20-D electric reach truck for reliable performance, advanced safety, and efficient warehouse management - every day, in every shift.
