- Description
The CDDK/CTDK series electric stacker is designed for general warehouse use, capable of short-to-medium travel distances. The foldable stand-on platform gives operator more flexibility.
Features
- Available with capacities from 1,200 to 1,500 kg
- Multiple lift heights available – 3,000 / 3,300 / 4,500 / 5,000mm
- Compatible with single-face, open face pallets only (CDDK series)
- Adjustable legs to accommodate varying pallet widths or closed face pallets (CTDK series)
- DC Brushless Traction Motor (for CDDK/CTDK12 only)
- High-performance AC Traction Motor (CDDK/CTDK15 only)
- German FREI Tiller Head
- European Steel Mast
- Side Battery Extraction
- Emergency reversing switch and creep speed button for additional safety in tight spaces.
- Automatic Speed Reduction on Cornering
- Foldable Stand-on Platform and Guard, enabling either pedestrian or stand-on operation.
- Electric Power Steering for additional operator comfort (CDDK/CTDK15 only)
- Hall-effect control system, reducing wear and tear on components.
- Equipped with Deep Cycle Battery (CDDK/CTDK12, CDDK/CTDK15-III)
- Equipped with Traction Battery (CDDK/CTDK15-II)
| Model | Load Capacity | Lifting Height | Distance between Fork-Arms | Battery Type | Motor Type |
|---|---|---|---|---|---|
| CDDK12III-Li | 1200 kg | 3000 / 3300 mm | 570 / 695 mm | Lithium | DC Brushless |
| CDDK15III-Li | 1500 kg | 3000 / 3300 mm | 570 / 695 mm | Lithium | AC + EPS |
| CDDK15II-Li | 1500 kg | 4500 / 5000 mm | 570 / 695 mm | Lithium | AC + EPS |
| CTDK12III-Li | 1200 kg | 3000 / 3300 mm | 200 - 800 mm (Adjustable fork) | Lithium | DC Brushless |
| CTDK15III-Li | 1500 kg | 3000 / 3300 mm | 200 - 800 mm (Adjustable fork) | Lithium | AC + EPS |
| CTDK15II-Li | 1500 kg | 4500 / 5000 mm | 200 - 800 mm (Adjustable fork) | Lithium | AC + EPS |
