Independently developed by Hangcha on the basis of more than 30 years of electric forklift research and development and accumulated manufacturing technology, the AE series electric forklifts are a new series of high-efficiency and energy-saving electric counterweight forklifts with a new structure that represents a breakthrough over the traditional design concept. The research and development of control and power systems are innovated and the product exterior, ergonomics, reliability, maintenance and other aspects are optimized, so that the performance of the vehicle is greatly improved.
Appearance
- With a profile formed by a combination of straight lines and streamlined curved surfaces, the truck is compact and maneuverable and has simple and sturdy appearance.
Comfort
- The cover is sealed with a good effect of rain resistance.
- The enlarged brake pedal and appropriate regenerative braking function can effectively reduce the driver's fatigue.
- The wide-view mast with optimized design is unlikely to obstruct the operator's sight. The enlarged opening size of the fork carriage enables a wider view.
Advancement
- The Y2 (Enpower controller) series uses 80V voltage system, both the traction and oil pump use permanent magnet synchronous motors, which have high efficiency, strong power and low energy consumption.
- The controller, oil tank and pump motor are all placed at the front to enable small pipeline length and less energy loss.
- The high-frequency MOSFET integrated controller ensures smooth and accurate traveling and lifting control, and has excellent speed regulation performance, good performance of electronic control matching the motor, functions of regenerative braking, reverse braking and anti-sliding on ramps, etc., and high safety and reliability.
Safety
- The optional lowering lock function can improve the safety greatly when the driver leaves the seat.
- The soft landing and electronic control lifting buffering (Opt.) are all provide to protect goods effectively.
- The handbrake can be optionally equipped with an alarm buzzer to prompt the driver to pull up the handbrake before leaving the truck.
Maintenance
- The front-opening hood design makes charging and maintenance easier.
- The electric control parts, fuse, etc. can be accessed easily and maintained without tools.
- The side-mounted oil tank facilitates liquid level check and oil addition.
Model | Load Capacity | Max Travel Speed | Max Lift Speed | Battery |
CPD15-AEY2 | 1.5t | 14 km/hr | 430 mm/sec | 80V 220Ah |
CPD20-AEY2 | 2.0t (mini) | 14 km/hr | 430 mm/sec | 80V 220Ah |
CPD20-AEY2 | 2.0t | 14 km/hr | 430 mm/sec | 80V 300Ah |
CPD25-AEY2 | 2.5t | 14 km/hr | 430 mm/sec | 80V 300Ah |
CPD30-AEY2 | 3.0t | 14 km/hr | 400 mm/sec | 80V 400Ah |
CPD35-AEY2 | 3.5t | 14 km/hr | 400 mm/sec | 80V 400Ah |
